| Model
No |
Flow
(m3/hr) |
Diameter
mm (D) |
Height
mm (H) |
Flange |
Media
Volume
(ℓ) |
BACK
WASH
FLOW RATE
(m3/hr) |
| In (A) |
Out (A) |
| AT-ACF-05S |
3~7 |
450 |
1,830 |
30 |
30 |
180 |
10 |
| AT-ACF-10S |
8~12 |
900 |
1,830 |
40 |
40 |
800 |
20 |
| AT-ACF-15S |
13~17 |
1,300 |
1,830 |
50 |
50 |
1,700 |
30 |
| AT-ACF-20S |
18~22 |
1,700 |
1,830 |
65 |
65 |
2,900 |
40 |
| AT-ACF-25S |
23~27 |
2,200 |
1,830 |
65 |
65 |
4,900 |
50 |
| AT-ACF-30S |
28~32 |
2,600 |
1,830 |
80 |
80 |
6,800 |
60 |
| AT-ACF-35S |
33~37 |
3,000 |
1,830 |
80 |
80 |
9,100 |
70 |
| AT-ACF-40S |
38~42 |
3,400 |
1,830 |
80 |
80 |
11,600 |
80 |
| AT-ACF-45S |
43~47 |
3,800 |
1,830 |
100 |
100 |
14,500 |
90 |
| AT-ACF-50S |
48~52 |
4,300 |
1,830 |
100 |
100 |
18,600 |
100 |
|
|
|
